Section 9 Periodical inspections and service
51
3. Oil and water supply list
Oil
maintenanc
e item
Oil type
Quantity of
oil
Inspection/
oiling
interval
Replacing
interval
Service
point
①
Implement (reel) C .G. 50 40
②
Cylinder C.C. 50 10
③
Lift arm C.G. 50 15
④
Hydraulic oil
transmission
G.O. 32 50 600 1
⑤
Rear axle case G.O. 1.3 50 600 1
⑥
Rear axle final G.O. 0.5 50 600 2
⑦
Hydraulic oil tank G.O. 38 50 600 1
⑧
Fuel tank F. 42
Before starting
operation
1
⑨
Engine oil E.O. 5.5 50 100 1
⑩
Radiator W. 6.5
Before starting
operation
1
⑪
Steering system C.G. 50 2
⑫
Pedal shaft C.G. 50 5
⑬
Battery D.W. 50 1
Oil used
E.O.
Diesel engine oil
All season, SAE10W/30
–5℃~25℃: SAE20W
10℃~35℃: SAE30
G.O.
HST oil, equivalent to ISO VG46
C.G.
Chassis grease or universal
grease No.2
F: Light oil
W: Coolant
D.W: Distilled water
Cautions:
Change both E.O and G.O after
the initial 50 hours of
operation.
When supplying oil, stop the
engine and keep away a fire.
If opening the radiator cap while
the engine is hot, be careful
sufficiently.
Supply oil to pins and links other than above ones as required.
● Supply oil to each linkage other than above ones as required.
