22
H2021 DRILL MOTOR
POS PART NAME NOTE QTY CPT CODE POS PART NAME NOTE QTY CPT CODE
1-1 WATER COCK-GARDENA 1 044137 57-3 ARMATURE 100V 1 052497
1-2 WATER COCK-SHIBUYA 1/4-φ16 1 000061 58 COLLAR 1 042152
2 OIL SEAL HMSA42557(SUS) 2 042178 59 BALL BEARING 6200DDW 1 045620
3 HEX. SOCKET BOLT M5×25 3 042179 60 FAN CASING 1 043080
4 SPRING WASHER 5 4 042180 61-1 TAPPING SCREW PANHEAD 5×85 220-240V 2 043081
6 SWIVEL RING 1 051922 61-2 TAPPING SCREW PANHEAD 5×80 110-120V 2 042682
7 SNAP RING SA63 1 005085 62-1 FIELD COIL 220-240V 1 052595
8 O-RING S55 1 042182 62-2 FIELD COIL 110-120V 1 045979
9 FIXING RING 1 051923 62-3 FIELD COIL 100V 1 043079
10-1 SPINDLE (U) 1 042728 63 MOTOR HOUSING W/DUSTPROOF SEAL 1 051948
10-2 SPINDLE (A) 1 042727 64 WASHER ROUND 6 7 042157
11 O-RING P28 2 000070 65 SPRING WASHER 2-6 4 042158
12 SEAL RING 1 042139 66 HEX SOCKET BOLT M6×90 4 042744
13 SPRING PIN 6×12AW(SUS) 1 000004 67 TAIL COVER 1 051949
14 BALL BEARING 6005DDU 1 001694 68 TAPPING SCREW PANHEAD 5×20 4 042161
15 BALL BEARING 6005ZZ 1 041710 69 BRUSH HOLDER 2 042162
16 SNAP RING-C 25 2 000689 70 SCREW TRUSS PC 4×14 2 042163
17 GEAR CASE 1 051941 71 CARBON BRUSH 2 049626
18 SHIFT POSITION STICKER 1 042186 72 BRUSH COVER 2 051929
19 PLATE 1 042187 73 TAPPING SCREW PANHEAD 4×20 2 042166
20 SCREW COUNTERSUNK M4×10 2 000712 74-1 MOTOR NAME PLATE 220-240V 2
21 STRIPPER BOLT MSB6.5-20 1 006509 74-2 MOTOR NAME PLATE 110-120V 2
22 COIL SPRING 1 000171 74-3 MOTOR NAME PLATE 100V 2
23 KNOB 1 043060 75-1 CIRCUIT PROTECTOR 220-240V NRAR1100-15AAA 1 001944
24 PARARREL PIN A5×10 1 006559 75-2 CIRCUIT PROTECTOR 110-120V NRAR1100-22ADA 1 051759
25 O-RING P8 1 042190 75-3 CIRCUIT PROTECTOR 100V NRAR1100-30ADA 1 044977
26 GEAR CHANGE SHAFT 1 042191 76 FASTEN TERMINAL 2 000057
27 LEVER 1 044746 77 CAP 2 000056
28 U-NUT FLANGED M5 1 042193 78-1 LEAD WIRE 110-120V/220-240V 1 043135
29 SHIM RING 2 042194 78-2 LEAD WIRE 100V 2 043097
30 METAL 1 042195 79 SWITCH BOX 1 043492
31 NO. 8 GEAR 1 051933 80-1 PLUG WITH CABLE & PRCD 220-240V EU/ASIA 1 042218
32 CLUTCH NO.3 1 051946 80-2 PLUG WITH CABLE & PRCD 220-240V DK 1 042783
33 SHIM RING 2 042199 80-3 PLUG WITH CABLE & PRCD 220-240V SA 1 050972
34 METAL 1 042200 80-4 PLUG WITH CABLE & PRCD 220-240V AU 1 051170
35 NO. 6 GEAR 1 042732 80-5 PLUG WITH CABLE 110-120V US 1 042781
36 SNAP RING-C 17 1 000272 80-6 PLUG WITH CABLE 110V UK 1 053048
37 NEEDLE BEARING TA 1512 Z/HMK1512 1 004630 80-7 PLUG WITH CABLE 100V TW 1 045969
38 BALL BEARING 6200ZZ 3 000030 81 SCREW HANHEAD B TIGHT 4×30 2 042171
39 NO. 3 GEAR 1 051939 82 CABLE SLEEVE 5311 1720 1 052825
40 PARARREL KEY 5×5×12 1 042872 83 INSULATION TUBE φ8×40 1 042174
41 NO. 2 GEAR 1 042734 84-1 CONDENSER 0.1μＦ/110V UK 1 000059
42 BALL BEARING 6202ZZ 1 000300 84-2 CONDENSER 0.1μＦ/220-240V 1 000059
43 NO. 7 GEAR 1 051934 85-1 CLOSED-END CONNECTOR 5.5SD / 110-120V/220-240V 2 000055
44 RING 1 006514 85-2 CLOSED-END CONNECTOR 5.5SD / 100V 3 000055
45 NO. 5 GEAR 1 042736 86 TAPPING SCREW PANHEAD 4×16 2 005495
46 CLUTCH 2 042737 87 CORD FIXER 6560067 1 042177
47 WASHER 2 042738 88 COLLAR 1 051950
48 METAL 1 042739 89 SCREW PANHEAD W/SW M4×10 1 000690
49 NO. 4 GEAR 1 051940 90 TERMINAL w/ INSULATION FVD2-M4 1 045679
50 SPRING PLATE MDS18-2 3 000014 91 RUBBER GASKET 1 044737
51 RING 1 006520 92 LABEL 1 052180
52 TWIN FU NUT TFU03SC 1 041776 93 DUSTPROOF SEAL 1 052033
53 BALL BEARING COVER 1 051947 94 DUST COVER NRAR 1 000131
54 O-RING S32 1 005389 95 TOOTHED WASHER TW ONLY 2 043085
55 HEX SOCKET PLUG 1/8 1 005386 96 SCREW PANHEAD W/SW M3×8 2 043093
56 BALL BEARING 6201HP 1 045618 97 WASHER 3 2 043094
57-1 ARMATURE 220-240V 1 100-1 ARMATURE ASSY 220-240V 56+57+58+59 1 052594
57-2 ARMATURE 110-120V 1 100-2 ARMATURE ASSY 110-120V 56+57+58+59 1 045983
100-3 ARMATURE ASSY 100V 56+57+58+59 1 052498
