23
CARRIAGE BLOCK FOR H2021
POS PART NAME NOTE QTY CPT CODE
1 SNAP RING-C 17 2 000272
2 SNAP RING-C 10 4 041411
3 BALL BEARING 6003-2VU 2 048379
4 PINION GEAR 1 051988
6 PARALLEL KEY 2 042637
7 SLIDING PLATE 2 042125
8 HEX SOCKET SCREW M6 x 12 2 042123
9 CARRIAGE BODY 1 052020
11 ROLLER WITH BUSH 8 049273
12 ROLLER SHAFT(F) 4 052005
13 ROLLER SHAFT(R) 2 042129
14 BACK COVER 1 042634
15 HEX. SOCKET BOLT M6 x 25 4 042131
16 HELISERT M8 x 1D 2 000458
17 HEX. SOCKET SCREW M8 x 12 2 042130
18 WEIGHT LABEL (CARRIAGE BLOCK) 1
19 GRIP HANDLE (RESIN) 1 042133
20 HEX. SOCKET BOLT FLANGED M6 x 30 2 042132
22 HEX. SCOCKET SCREW 4 042126
23 HEX. SOCKET BOLT w/SW M8 x 30 4 042391
24 STOPPER-KNOB M10 1 042268
25 HEX. BOLT M10 x 40(COPPER) 1 042267
26 U-NUT 3-M10 2 043045
27 30MM SPACER BODY 1 052024
28 SPRING WASHER 2-8 4 042824
29 HEX. SOCKET BOLT M8 X 60 4 042823
30 30MM SPACER SET 1 052023
CARRIAGE BLOCK CPL. excl. POS. 30 1 052910
