25
POS PART NAME NOTE QTY CPT CODE
3 HEX. BOLT M12×70 2 042650
4 SPRING WASHER 2-12 2 042098
10 LEVELING BOLT(F) 2 042648
11 HEX. NUT 1 -W1/2 4 042651
12 U-NUT 1-M20 2 042825
13 PLAIN WASHER 20 2 042656
14 BEAM 2 042657
15 HEX. BOSS (F) 2 042652
16 LEVELING BOLT(R) 2 042649
17 HEX. BOSS (R) 2 042653
18 BASE PLATE 1 042646
TS-255 BASE CPL. 1 042644
POS PART NAME NOTE QTY CPT CODE
1 DEPTH GAUGE DECAL (mm) 1 000520
2 RACK GEAR 800L 1 004688
2 RACK GEAR 1000L 1 004670
5 PIPE BOSS 2 005164
19 COLUMN 800L 1 041944
19 COLUMN 1000L 1 002046
20 DEPTH GAUGE DECAL (inch) US VERSION ONLY 1 044497
21 WEIGHT LABEL (TS-255 800L) 1
21 WEIGHT LABEL (TS-255 1000L) 1
COLUMN CPL. 800L 1 005659
COLUMN CPL. 800L US VERSION 1 051678
COLUMN CPL. 1000L 1 051679
COLUMN CPL. 1000L US VERSION 1 051680
8 HEX. SOCKET BOLT M6 X 12
4 (FOR 800L)
6 (FOR 1000L)
004672
TS-255 BASE AND COLUMN 800L AND 1000L
COLUMN
BASE
8
19
20
1
3
4
5
13
18
17
11
16
15
14
12
11
10
2
21
To Next Page
