Shihlin electric SF3 Series User Manual

D8052
Output current monitoring
Monitor output current, unit 0.01A
R
D8053
Output voltage monitoring
Monitor output voltage, unit 0.01V
R
D8054
Alarm record 1, 2
Surveillance alarm 1, 2
R
D8055
Alarm record 3, 4
Surveillance alarm 3, 4
R
D8056
2-5 terminal analog input
Monitor 2-5 terminal analog input,
The smallest unit is 0.1%, and the range is
-100%~100%.
R
D8057
4-5 terminal analog input
Monitor 4-5 terminal analog input,
The smallest unit is 0.1%, and the range is
0% to 100%.
R
D8058
3-5 terminal analog input (SA3, SF3)
Monitor 3-5 terminal analog input,
The smallest unit is 0.1%, and the range is
0% to 100%.
R
D8059
Monitoring status type customization
The setting is equivalent to the external
output terminal function setting. Refer to
P.40 for instructions.
R/W
D8060
High-speed input counter current value
(lower sixteen digits)
Monitor the lower 16 bits of the current
count.
R
D8061
Current value of high-speed input counter
(high sixteen digits)
Monitor the high 16 bits of the current
count. (Note 1)
R
D8128
Inverter mode setting
P.79 = 0
0: set to PU mode
1: Set to external mode
2: Set to JOG mode
P.79 = 1
0: set to PU mode
1: invalid
2: Set to JOG mode
P.79 = 3
0: P.35 = 0 is set to CU mode, P.35 = 1 is
set to external mode
1: Set to external mode
2: Set to communication JOG mode
The above mode can be modified only
when M8036 bit is 1.
R/W
D8129
Linear speed feedback setting
Minimum unit 0.1 m/min
R/W
D8130
Linear speed target value setting
Minimum unit 0.1 m/min
R/W
D8131
Tension setting
Minimum unit 1N
R/W
D8132
Torque setting
H0000~H0FA0(0~400.0%)
HF060~HFFFF (-400.0%~0) minimum unit
0.1%
R/W
D8135
2-5 terminal input monitoring
H0000~H03E8(0~10.00)
HFF9C~HFFFF(-10.00~0)
The smallest unit is 0.01V
R
D8136
4-5 terminal input monitoring
The smallest unit is 0.01mA/V
R
D8137
3-5 terminal input monitoring (SA3, SF3)
The smallest unit is 0.01mA/V
R
D8138
AM1-5 terminal output monitoring (SA3,
SF3)
The smallest unit is 0.01mA/V
R
AM-5 terminal output monitoring (SE3)
D8139
AM2-5 terminal output monitoring (SA3,
SF3)
The smallest unit is 0.01mA/V
R
D8140
DC bus voltage monitoring
Minimum unit 1V
R
