4-47Control output 1 soft start time setting screen
Initial value: oFF
Setting range: oFF, 1 – 120 (seconds)
Sets soft start time that gradually changes output.
Does not function if oFF is set.
For details, see 8-6.
4-48 Output 2 proportional cycling time setting screen
Initial value: Contact output: 30 (seconds),
SSR drive voltage output: 3 (seconds)
Setting range: 1 – 120 (seconds)
Sets control output 2 proportional cycling time.
Displayed if Y, P is selected for control output 2.
4-49Control output 2 characteristics setting screen
Initial value: dA (
)
Setting range: rA (
), dA
Sets characteristics of control output.
(RA) : Reverse characteristics (for heating)
(DA) : Direct characteristics (for cooling)
Displayed if Y, I, P, V is selected for control output 2.
4-50Control output 2 soft start time setting screen
Initial value: oFF
Setting range: oFF, 1 – 120 (seconds)
Sets soft start time that gradually changes output.
Does not function if oFF is set.
For details, see 8-6.
Displayed if Y, I, P, V is selected for control output 2.
4-51 SV limiter lower limit setting screen
Initial value: Lower limit value of measuring range
Setting range: Lower limit value of measuring range to higher
limit value of measuring range - 1 count
If using setting range of target values below measuring range:
Set lower limit value.
(Able to prevent incorrect setting in danger range, etc.)
4-52SV limiter higher limit setting screen
Initial value: Higher limit value of measuring range
Setting range: Lower limit value of SV limiter + 1 count to
higher limit value of measuring range
If using setting range of target values below measuring range:
Sets higher limit value.
(Able to prevent incorrect setting in danger range, etc.)
If Sc_L/Sc_H are changed, the respective values are set for
SV_L/SV_H.
4-53 Number of patterns setting screen
(Displayed only when programming function is selected)
Initial value: 4
Setting range: 1, 2, 4
Sets number of patterns used by programming function.
4-54 Time unit setting screen
(Displayed only when programming function is selected)
Initial value: Hm (
)
Setting range: Hm, mS (
)
Sets time unit used by programming function.
Hm: Hour/minute, mS: Minute/second
4-55PV bias value setting screen
Initial value: 0 (digit)
Setting range: -1999 – 2000 (digit)
Used for compensating input error of sensors, etc.
When bias is applied, control is also executed according to the
compensated value.
4-56PV gain compensation value setting screen
Initial value: 0.00 (%)
etting range: -5.00 – 5.00 (%)
Used for compensating input gain error of sensors, etc.
When gain compensation is applied, control is also executed
according to the compensated value.
4-57PV filter time setting screen
Initial value: 0 (seconds)
Setting range: 0 – 9999 (seconds)
Used to alleviate the effect if input varies radically or
noise is superimposed.
Filter does not function if set to 0 seconds.
4-58Measuring range code setting screen
Initial value: Multi: 05, voltage: 86
Setting range: Selected from “Chapter 7: Measuring Range Codes.”
Combination of input type and measuring range is set by the code.
Setting cannot be changed during control action.
4-59Input unit setting screen
Initial value: c (
)
Setting range: c, F (
)
Temperature unit for sensor input is set to C (°C) or F (°F).
Not displayed if linear input (mV, V) is selected.
K(
) is displayed if measuring range code is 15 – 18 (in kelvin).
Modification of unit is only possible when in standby mode.
4-60Input scaling lower limit value setting screen
Initial value: 0.0 (digit)
Setting range: -1999 – 9989 (digit)
Sets scaling lower limit value for linear input (mV, V).
Cannot be set by monitoring screen for sensor input.
4-61Input scaling higher limit value setting screen
Initial value: 100.0
Setting range: (Sc_L setting value) + 10 – (Sc_L setting value)
+ 10,000
Sets scaling higher limit value for linear input (mV, V).
Cannot be set by monitoring screen for sensor input.
4-62Input decimal point position setting screen
Initial value: 1 digit following decimal point (0.0)
Setting range: No decimal point (0) – 3 digits following
decimal point (0.000)
Except for linear input, no decimal point (0) – 1 digit following
decimal point (0.0)
Sets decimal point position for input scaling.
Range with no decimal point cannot be set by monitor alone.
4-63 Basic screen display mode
Initial value: PVSV (
)
Setting range: PVSV / PV (
) / SV (
)
PVSV: Normal display (both PV and SV displayed)
PV : PV value only displayed
(SV value cannot be modified on basic screen)
SV : SV value only displayed (PV value masked)
4-64 Hysteresis mode
Sets hysteresis mode when ON/OFF action is selected.
The set mode will be reflected in all of the following:
OUT1/2 and PID1/2/3.
Initial value: CENT (
)
Setting range: CENT/SVOF (
)SVON (
)
CENT: Mode for making the center position of hysteresis SV value
SVOF: Mode for making the output OFF position of hysteresis SV value
SVON: Mode for making the output ON position of hysteresis SV value
To 4-0 screen
Note:
For SV limiter setting, the lower limit value is given
preference when SV limiter lower limit value is less than
higher limit value. Consequently, higher limit cannot be
set less than lower limit value + 1 count.
To 4-56 screen
Note:
Setting cannot be changed during control action on
4-58
4-62 screen.
To Next Page
