10-3. Mask/lock setting contents
(1) Settings for various parameters
: Displays parameter setting screen.
:Masks parameter setting screen.
:Displays parameter setting screen but keys are locked.
The "dp" on the far right of the SV display lights to indicate key lock.
(2) Settings for each screen group
:Setting
on the M1-0, M2-0, M3-0, M4-0 screens displays the target screen group.
Setting contents for the various parameters are applied.
:Setting
on the M1-0, M2-0, M3-0, M4-0 screens masks the target screen group.
• Setting
on the M1-0 screen masks the M1-1 – M1-5 and 1 screen group.
• Setting
on the M2-0 screen masks the M2-1 – M2-16 and 2 screen group.
• Setting
on the M3-0 screen masks the M3-1 – M3-12 and 3 screen group.
• Setting
on the M4-0 screen masks the M4-1 – M4-63 and 4 screen group.
: Setting
on the M1-0, M2-0, M3-0, M4-0 screens locks the keys of the target screen group.
Parameters set to
are masked and parameters set to
/
are displayed but the keys are locked.
(3) Mask/lock initialization
If turned from OFF to ON on the M0-1 all parameters reset screen, mask/lock is reset for all parameter and becomes
.
M4-0
M4-1
M4-2
M4-3
M4-4
M4-5
M4-6
M4-7
M4-8
M4-9
M4-10
M4-11
M4-12
M4-13
M4-14
M4-15
M4-16
M4-21
M4-22
M4-23
M4-24
M4-25
M4-26
M4-27
M4-28
M4-29
M4-30
M4-31
M4-32
M4-33
M4-34
M4-44
M4-50
M4-51
M4-55
M4-56
M4-57
M4-58
M4-59
M4-60
M4-61
M4-52
M4-53
M4-54
M4-17
M4-18
M4-19
M4-20
Initial screen
Key lock setting
EV1 mode setting
EV1 hysteresis setting
EV1 standby action
setting
EV1 latching setting
EV1 output
characteristics setting
Heater 1 break alarm
setting
Heater 1 loop alarm
setting
Heater 1 alarm mode
setting
EV2 mode setting
EV2 hysteresis setting
EV2 standby action
setting
EV2 latching setting
EV2 output
characteristics setting
EV3 mode setting
EV3 hysteresis setting
EV3 standby action
setting
EV3 latching setting
EV3 output
characteristics setting
Heater 2 alarm mode
setting
Analog output type
setting
Analog output scaling
lower limit value setting
Analog output scaling
higher limit value setting
Analog output limiter
lower limit setting
Analog output limiter
higher limit setting
DI1 mode setting
DI2 mode setting
DI3 mode setting
DI4 mode setting
Communication mode
setting
Communication
address setting
Communication data
format setting
Communication start
character setting
Communication BCC
operation/protocol type setting
Communication speed
setting
Communication delay
time setting
Communication
memory mode setting
Communication mode
types
Communication master mode
start slave address setting
Heater 2 break alarm
setting
Heater 2 loop alarm
setting
Output 1 proportional
cycling time setting
Output 1 characteristics
setting
Output 1 soft start time
setting
Output 2 soft start time
setting
Output 2 proportional
cycling time setting
Output 2 characteristics
setting
SV limiter lower limit
value setting
SV limiter higher limit
value setting
Number of program
patterns setting
Program time unit
setting
PV bias value setting
PV gain compensation
value setting
PV filter time setting
Measuring Range
Codes setting
Temperature unit
setting
Input scaling lower limit
value setting
Input scaling higher
limit value setting
Input decimal point
setting
Communication master mode
finish slave address setting
Communication master mode
write data address setting
M4-35
M4-36
M4-37
M4-38
M4-39
M4-40
M4-41
M4-42
M4-43
M4-45
M4-46
M4-47
M4-48
M4-49
M0-0 Mask lock basic screen
M4 screen group
4-21 screen 4-42 screen
4-0 Initial screen
M4-62
Basic screen display
mode
Communication master
mode setting
M4-63
2 seconds
Hysteresis mode
M4-64
