1. COMPONENTS AND THEIR NAMES
Components Included with every balance are one of the following items.
• Balance body • AC adapter (option) • protection cover
• Pan • Pan supporter • Instruction manual
• Inspection certificate • Breeze guard (Only type, BL220H (L) and
BL320H (L)).
○
1
Balance body ○
2
Pan ○
3
Pan supporter
○
4
Pan shaft ○
5
Level gauge ○
6
Power jack
○
7
Level screws (3 places) ○
8
Protection cover ○
9
AC adapter (option)
○
10
Data I/O connector ○
11
Breeze guard (Only BL220H (L) and BL320H (L))
○
12
Breeze guard cover (Only BL220H (L) and BL320H (L))
