About the Setting Menus
Accessing the Setting Menu
SW-E8000-L/SC-E8000
1. Hold down A when the bicycle is not moving to display the menu
list screen.
A
SW-E8000-L/SC-E8000
SW-E6000/SC-E6010 SW-E6010/SC-E6010
1. Hold down X and Y when the bicycle is not moving to display the
menu list screen.
X
Y
SW-E6010/SC-E6010
X
Y
SW-E6000/SC-E6010
<SC-E8000>
<SC-E6010>
2. Press X or Y to select the various menus. Press A to display the setting screen for the selected menu.
XY A
SW-E8000-L/SC-E8000
(A)
Clear settings
(B)
Clock setting
(C)
Bluetooth LE pairing
(D)
Bluetooth LE/ANT connection status
(E)
Turning the light on/off
(F)
Display backlight brightness setting
(G)
Turning the beep noise on/off
(H)
Switching between km and miles
(I)
Language setting
(J)
Adjusting the electronic gear shifting unit
(K)
Activating RD Protection Reset*
(L)
Return to the main screen
<SC-E8000>
(A) Clear Exit (L)
(B) Clock
RD
protection
reset
(K)
(C) Bluetooth LE Adjust (J)
(D)
Bluetooth LE/
ANT
Language (I)
(E) Light Unit (H)
(F) Brightness Beep (G)
A
X
Y
SW-E6000/SC-E6010
X
Y
A
SW-E6010/SC-E6010
(A)
Clear settings
(B)
Clock setting
(C)
Turning the display backlight on/off
(D)
Display backlight brightness setting
(E)
Turning the beep noise on/off
(F)
Switching between km and miles
(G)
Language setting
(H)
Changing the font color
(I)
Adjusting the electronic gear shifting unit
(J)
Activating RD Protection Reset*
(K)
Return to the main screen
[Start mode] and [Auto] are displayed on the menu list screen; however, they are not
available for use.
<SC-E6010>
(A) Clear Exit (K)
(B) Clock
RD
protection
reset
(J)
(C) Backlight
(D) Brightness Adjust (I)
(E) Beep Font color (H)
(F) Unit Language (G)
* In order to protect the system from falling down etc., if the bicycle is subjected to a strong impact, the RD Protection function will operate and
the connection between the motor and the link will be momentarily severed so that the rear derailleur can no longer operate. Executing RD
Protection Reset restores the connection between the motor and the link, as well as the function of the rear derailleur.
