INSTALLATION/REMOVAL
Installing the brake lever
3. Attach the brake lever to the handlebar.
Secure the lever using the mounting bolt.
Mounting bolt
4 - 6 N·m
Shifting lever band
When installing the brake lever in combination with a standard type shifting
lever, install the brake lever so that the position of the shifting lever band is
within the range shown in the figure. After the shifting lever is installed, install
the brake lever while checking its position.
