INSTALLATION/REMOVAL
Installing the brake hose
NOTICE
• Use the supplied snap rings. Other models of
snap rings cannot be installed.
Installing the brake hose
Overview of the easy hose joint system
Brake caliper
Brake hose connection port
Lever stopper
Hose cap
Brake lever
