INSTALLATION/REMOVAL
Installing the brake caliper
International-standard mount type
NOTICE
• For international-standard mounts, a dedicated adapter is required.
1. Install the wheel with an attached disc brake rotor onto the frame.
2. Remove the bleed spacer (yellow).
(1) Close the tip of the split pin.
(2) Remove the split pin.
(3) Remove the bleed spacer (yellow).
Bleed spacer (yellow)
(1)
(2)
(3)
Split pin
3. Set the brake pad presser spring in the brake pads.
Since there are fins on the front and rear of the finned pads, set the pads as shown in the
figure.
When a brake pad has markings, take note of the left (L) and right (R) markings to set it.
Brake pad presser spring
Finned pads
