18
INSTALLATION/REMOVAL
Installing the brake caliper
6. Depress the brake lever so that the disc brake rotor is held between
the pads, and then tighten the caliper fixing bolts.
If the brake hose is not already installed in the caliper, install the brake hose and then
perform the step.
6 - 8 N·m
Caliper fixing bolts
7. Secure the caliper fixing bolt.
In order to prevent the bolt from loosening, install a snap ring on the head of the bolt.
Snap ring
NOTICE
• Use the supplied snap rings. Other models of
snap rings cannot be installed.
To Next Page
