22
INSTALLATION/REMOVAL
Installing the brake caliper
6. Depress the brake lever so that the disc brake rotor is held between
the pads, and then tighten the caliper fixing bolts.
If the brake hose is not already installed in the caliper, install the brake hose and then
perform the step.
Caliper fixing bolts
6 - 8 N·m
Caliper fixing bolts
6 - 8 N·m
7. Secure the caliper fixing bolt.
In order to prevent the bolts from loosening, secure the caliper fixing bolt and adapter
fixing bolts with snap rings as indicated in the figure.
Snap ring
