27
INSTALLATION/REMOVAL
Installing the brake hose
2. Add a cut mark.
Add a cut mark 18 mm towards the end of the hose from the witness mark.
* When not using an easy hose joint system, add a cut mark 11 mm towards the end of
the hose from the witness mark.
Cut mark
Witness mark
3. Prepare tool TL-BH62 for the cutting of the brake hose.
Disassemble the tool as shown in the figure.
Hose cutter
Main body
Press block
[3] [4]
To Next Page
