50
MAINTENANCE
SHIMANO genuine mineral oil replacement
14.
Tilt the brake lever downwards 30° from the ground and conduct step
11.
Check that there are no remaining air bubbles.
30°
15.
Set the brake lever so that it is parallel to the ground.
16.
Plug the oil funnel with the oil stopper.
Make sure that the side of the oil stopper with the O-ring attached is facing downward.
O-ring
17.
Remove the oil funnel while it is still plugged by the oil stopper.
