ADJUSTMENT
Installing the inner cable and adjusting gear shifting
ADJUSTMENT
Installing the inner cable and adjusting gear
shifting
Securing the cable
1. Operate the release lever on the dual control lever and set it to the
initial position (on the smallest chainring side).
2. Remove the link cover.
Link cover
TECH TIPS
• When removing the link cover, lift it up while
rotating it in the direction of the arrow as
shown in the figure.
To Next Page
