Shimano FD-RX810 - Adjusting Cable Tension

19
ADJUSTMENT
Installing the inner cable and adjusting gear shifting
5. Secure the inner cable.
Secure while pulling the cable.
6 - 7 N·m
Cable fixing bolt
Adjusting cable tension
1. Align with the gear where the lever is released from the top position
to the T-trim position.
L-trim
T-trim
Low
Tension adjustment
point
Top
