MAINTENANCE
Replacing the skid plate
MAINTENANCE
Replacing the skid plate
Removing the skid plate
1. Remove the skid plate.
Make a slit in the skid plate at the position illustrated using nippers, and then remove the
skid plate.
NOTICE
• The skid plate on the outer plate side cannot be replaced.
Installing the skid plate
1. Install a new skid plate.
(1) Insert the skid plate into the mounting hole.
(2) Check that the claws on the skid plate are engaged properly on the back side of the
inner plate.
Mounting holes
