8
INSTALLATION/REMOVAL
Installing the front derailleur
2. Install the backup plate.
Avoid positioning the tape that attaches the backup plate to the seat tube in the location
where the support bolt directly touches the frame.
Backup plate
Backup plate
Tape
Support bolt
