Shimano MTB SHADOW RD-M786 - Page 13

13
3. Using a 3 mm Allen key, remove the end adjust bolt.
4. Using a 3 mm Allen key, push the bottom of the bump stopper to remove it.
Push a 3 mm Allen key into the
screw hole.
Bump stopper
4
End adjust bolt
3
4
Push
3 mm Allen key
Bump stopper
5. Push in the bump stopper with a 1.5 mm Allen key in the low state as shown in the illustration.
1.5 mm Allen key
