Shimano MTB SHADOW RD-M786 - Replacing the Pulley

26
 Replacing the pulley
Guide pulley
without arrows
with arrows
Tension
pulley
3 mm Allen key
E-ring
Note (RD-M986/M981/M820):
• When removing the tension pulley, remove the E-ring first.
Guide pulley/Tension pulley
Tightening torque:
2.5 - 5.0 N·m {22 - 44 in. lbs.}
