8
Mode converter (RD-M820)
This derailleur is compatible with two types of sprockets: Freeride mode (11-32T/11-34T/11-36T) and downhill mode (11-23T/12-
25T/11-28T).
If using the freeride mode sprockets, you will also need to use the mode converter.
Removing the mode converter
Mode converter
2 mm Allen key
Tightening torque:
1.0 - 1.5 N·m {9 - 13 in. lbs.}
When a mode converter is installed
When a mode converter is not installed
Bracket
Dropout
