17(77)
alarm.
6) Before turn off the pump, wait until oil temperature falls blow 50℃. Or the life
of the unit would be affected.
1.4.4 Transportation and Storage of the Machine
Transportation
1) STM-W/O series are packed in crates or plywood cases with wooden pallet at
the bottom, suitable for quick positioning by fork lift.
2) After unpacked, castors equipped on the machine can be used for ease of
movement.
3) Do not rotate the machine and avoid collision with other objects during
transportation to prevent improper functioning.
4) The structure of the machine is well-balanced, although it should also be
handled with care when lifting the machine for fear of falling down.
5) The machine and its attached parts can be kept at a temperature from -25℃
to +55 ℃ for long distance transportation and for a short distance, it can be
transported with temperature under +70℃.
Storage
1) STM-W/O series should be stored indoors with temperature kept from 5 ℃ to
40 ℃ and humidity below 80%.
2) Disconnect all power supply and turn off main switch and control switch.
3) Keep the whole machine, especially the electrical components away from
water to avoid potential troubles caused by the water.
4) Plastic film should be used to protect the machine from dust and rains.
Working environment
The machine should be operated:
1) Indoors in a dry environment with max. temperature +45 ℃ and humidity no
more than 80%.
Do not use the machine:
1) If it is with a damaged cord.
2) On a wet floor or when it is exposed to rain to avoid electrical shock.
3) If it has been dropped or damaged until it is checked or fixed by a qualified
To Next Page
