39(77)
2.3.8 Electrical Components List (STM-907W/O) (400V)
Table 2-9：Electrical Components List (STM-907W/O) (400V)
NO. Symbol Name Specification Part NO.
1 Q1 Main switch* 25A YE10125250000
2 Q2
Circuit breakers** 25A YE40602500000
3 -
Excitation break away - YE40023560000
4 K1 K2
Contactors* 220V 50/60Hz YE00601522000
5 -
Auxiliary contact terminal 1NO YE00691110000
6 K3
Contactors** 220V 50/60Hz YE00601800000
7 K4
Contactors** 220V 50/60Hz YE00601621000
8 F1
Overload relays 1.8~2.5A YE01160180000
9 F11
Fuse box** 32A 2P YE41032200000
10 -
Fuse** 2A YE46002000100
11 F12
Fuse** 2A YE41001000000
12 T
Transformer* IN=400V OUT=230V 500mA YE70402300800
13 S1
Thermocouple - -
14 S2 S3
Thermocouple - -
15 S4
Overheat protector* - -
16
S5
Micro-switch* - YE14152400000
17
PC1
Circuit board** 100~240VAC 50/60Hz
18
A
Control panel -
YE81100010000
19 Y1 Y2 Y3 Solenoid valve** 230VAC 50/60Hz -
20 X1 Terminal board - YE61250040000
21
- Terminal board - YE61253500000
22 - Terminal board - YE61040000000
23 - Terminal board - YE61043500000
24 M1 Motor** 400V 50Hz 0.5kW -
25 EH1 Heater** 400V 50Hz 6kW -
26 EH2 Heater** 400V 50Hz 3kW -
27 FM1 Fan* 230V 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
