47(77)
2.3.16 Electrical Components List (STM-907W/O) (230V)
Table 2-11：Electrical Components List (STM-907W/O) (230V)
NO. Symbol Name Specification Part NO.
1 Q1 Main switch* 32A YE10323200000
2 Q2
Circuit_breakers** 32A YE40603200000
3 -
Excitation break away - YE40023560000
4 K1 K2
Contactors* 220V 50/60Hz YE00601522000
5 -
Auxiliary contact terminal 1NO YE00691110000
6 K3
Contactors** 220V 50/60Hz YE00602522000
7 K4
Contactors** 220V 50/60Hz YE00601621000
8 F1
Overload relays 2.8~4A YE01160280000
9 F11
Fuse box** 32A 2P YE41032200000
10 -
Fuse** 2A YE46002000100
11 S1
Thermocouple - -
12 S2 S3
Thermocouple - -
13 S4
Overheat protector* - -
14 S5
Micro-switch* - YE14152400000
15 PC1
Circuit board** 100~240VAC 50/60Hz YE80000100000
16 A
Control panel -
17 Y1 Y2 Y3 Solenoid valve** 220VAC 50/60Hz -
18 X1 Terminal board - YE61250040000
19 - Terminal board - YE61253500000
20 - Terminal board - YE61040000000
21 - Terminal board - YE61043500000
22 M1 Motor** 230V 50Hz 0.5kW -
23 EH1 Fan* 230V 50Hz 6kW -
24 EH2 Fan* 230V 50Hz 3kW -
25 FM Fan* 230VAC 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
