-29-
Model D4902 (For Machines Mfd. Since 11/18)
PARTS
Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 XD4902001 LOCK HANDLE 68L, M8-1.25 37 XD4902037 LOCK WASHER 10MM
2 XD4902002 FLAT WASHER 5/16 38 XD4902038 CLAMP BRACE
3 XD4902003 SET SCREW M8-1.25 X 55 39 XD4902039 WARNING LABEL
4 XD4902004 LOCK HANDLE 45L, M6-1 X 25 40 XD4902040 RIVET 2 X 5MM NAMEPLATE, STEEL
6 XD4902006 LOCK BUSHING 41 XD4902041 ROLL PIN 10 X 45
7 XD4902007 FIXED HANDLE 26 X 100, M10-1.5 X 15 42 XD4902042 CLAMP BRACKET
8 XD4902008 KNOB 5/16-18, D1-1/4, ROUND KN 43 XD4902043 FLAT WASHER 5/16
9 XD4902009 SET SCREW M6-1 X 8 44 XD4902044 CAP SCREW M8-1.25 X 50
10 XD4902010 BUSHING 45 XD4902045 HANDWHEEL TYPE-3 100D X 10B-S X 1/4-20
11 XD4902011 MICRO-ADJUST COLLAR 46 XD4902046 REV. HANDLE 5/8 X 2-1/8, 1/4-20 X 3/8
12 XD4902012 SET SCREW M6-1 X 8 47 XD4902047 SET SCREW 1/4-20 X 1/4
13 XD4902013 FLAT WASHER 10MM NYLON 48 XD4902048 CLAMP SHOE W/LEADSCREW
14 XD4902014 HEX NUT M10-1.5 50 XD4902050 FLAT WASHER 1/4
15 XD4902015 LEADSCREW M10-1.5 X 81 51 XD4902051 SIDE SUPPORT
16 XD4902016 GUIDE BUSHING 52 XD4902052 SET SCREW M6-1 X 16
17 XD4902017 GUIDE ROD 53 XD4902053 T-SLOT GUIDE WASHER
18 XD4902018 SET SCREW M6-1 X 45 54 XD4902054 FLAT HD CAP SCR M6-1 X 20
19 XD4902019 HEX NUT M6-1 55 XD4902055 SET SCREW M6-1 X 25
20 XD4902020 SLIDE PLATE 57 XD4902057 BACK SUPPORT BRACKET
21 XD4902021 SCALE LABEL 58 XD4902058 SQUARE NUT M6-1
22 XD4902022 PHLP HD SCR M5-.8 X 10 59 XD4902059 SHOULDER SCREW M5-.8 X 10, 6 X 3
24 XD4902024 FLAT WASHER 1/4 60 XD4902060 FLAT HD SCR 1/4-20 X 3/8
25 XD4902025 SIDE SUPPORT BRACKET 61 XD4902061 CAP SCREW M10-1.5 X 20
26 XD4902026 LOCK BUSHING M6-1 62 XD4902062 LOCK BUSHING
27 XD4902027 HEX NUT M8-1.25 63 XD4902063 HEX NUT M5-.8
28 XD4902028 PHLP HD SCR M4-.7 X 6 64 XD4902064 SET SCREW M5-.8 X 20
29 XD4902029 SCALE POINTER 65 XD4902065 HEX WRENCH 3MM
30 XD4902030 BUTTON HD CAP SCR M6-1 X 20 66 XD4902066 HEX WRENCH 4MM
32 XD4902032 BASE PLATE 67 XD4902067 HEX WRENCH 6MM
33 XD4902033 BUTTON HD CAP SCR M6-1 X 20 68 XD4902068 HEX WRENCH 8MM
34 XD4902034 GUIDE BAR 69 XD4902069 HEX WRENCH 2.5MM
36 XD4902036 CAP SCREW M10-1.5 X 25 71 XD4902071 WAVY WASHER 6MM
Safety labels warn about machine hazards and how to prevent serious personal injury. The owner
of this machine MUST maintain the original location and readability of all labels on this machine.
If any label is removed or becomes unreadable, REPLACE that label before allowing machine to
be operated again. Contact us at (360) 734-3482 or www.woodstockint.com to order new labels.
