SHOWTEC ColorCue 3 - MIDI Implementation Chart

21
Order code: 50705
ColorCue 3
MIDI Implementation Chart
Function
Transmitted
Recognized
Remarks
Basic channel
Default
Changed
1
X
1
X
Mode
Default
Messages
Altered
X
X
Note number
True voice
22–85
X
22–84
X
*1
Velocity
Note ON
Note OFF
O
X
O
X
*2
After touch
Key's
Channel
X
X
X
X
Pitch bend
X
X
Control change
X
X
Prog Change
True#
X
X
X
X
SysEx
X
X
Common
Song pos
Song Sel
Tune
X
X
X
X
X
X
System real time
Clock
Commands
X
X
X
X
Aux Messages
Local ON/OFF
X
X
All Notes OFF
X
X
Active Sense
X
X
Reset
X
X
O:YES Mode 1: OMNI ON, POLY Mode 2: OMNI ON, MONO
X:NO Mode 3: OMNI OFF, POLY Mode 4: OMNI OFF, MONO
*1 table 1: note numbers
note number
function
22–45 (16H – 2DH)
Channel 1–24
46 (2EH)
Red
47 (2FH)
Green
48 (30H)
Blue
49 (31H)
White
50 (32H)
Amber
51 (33H)
UV
52 (34H)
X-fade A
53 (35H)
X-fade B
54–77 (36H – 4DH)
Flash 1–24
78 (4EH)
Fixtures
79 (4FH)
Manual
80 (50H)
Mode
81 (51H)
Auto
82 (52H)
Single
83 (53H)
Hold
84 (54H)
Black out
85 (55H)
Clear (only transmitted, not recognized)
*2
On OR LED Green: Velocity > 0
Off OR LED Red: Velocity = 0
except: note number 54–77 which can be toggled using only note on commands
(velocity > 0)
note number 22–53: The intensity is controlled by velocity.
