Compact Par 7 MKII
6.Sound control Mode
01) Press the MODE button on the device, until the display shows .
02) Press the SETUP button to open this menu.
03) Use the UP/DOWN buttons to change the values.
04) Set the value of the sound control mode (0-31) .
DMX Channels
3 Channels
Channel 1 – Red Dimmer intensity
0-255
Red from 0 – 100%
Channel 2 – Green Dimmer intensity
0-255
Green from 0 – 100%
Channel 3 – Blue Dimmer intensity
0-255
Blue from 0 – 100%
6 Channels
Channel 1 – Dimmer (Colors RGB must be open )
0-255
From black to brightest
Channel 2 – Red Dimmer intensity (CH1 must be set between 0-255 )
0-255
Red from 0 – 100%
Channel 3 – Green Dimmer intensity (CH1 must be set between 0-255 )
0-255
Green from 0 – 100%
Channel 4 – Blue Dimmer intensity (CH1 must be set between 0-255 )
0-255
Blue from 0 – 100%
Channel 5 – Sound active (Use in combination with CH6 )
0-10
No use
11-255
Sound active
Channel 6 – Shutter / Strobe (CH1, CH2, CH3 or CH4 must be set between 1-255 )
0-10
No function
11-255
Strobe (color strobe selected by 1CH-4CH)
Channel 6 – Sound sensitivity (CH5 must be set between 11-255 )
0-255
Sound sensitivity
