SHOWTEC compact par 7 MKII User Manual

21
Ordercode: 42595
Compact Par 7 MKII
Product Specification
Model:
Showtec Compact Par 7 MKII
Input Voltage:
100-240 VAC
Drive current:
0,68A/110V, 0,32A/240V
Continuous Power:
28W max. at full output
Power linking:
20pcs@110V, 38pcs@240V
Dimensions:
200 x 95 x 220 mm (LxWxH)
Weight:
1,56 kg
Operation and Programming
Signal pin OUT:
pin 1 earth, pin 2 (-), pin 3 (+)
Set Up and Addressing:
LED control panel
DMX Channels:
3, 6 or 7
Signal input:
3-pin XLR male
Signal output:
3-pin XLR female
Electro-mechanical effects
LED Quantity:
7 x 3-in-1 LED
Colormixing:
RGB
Colour range:
16,7 million additive colors
Lightoutput
High Power
IP Rating:
IP20
Housing:
Specially designed housing ensures an optimum heat
dissipation during operation
Mounting:
Multiple mounting possibilities
DMX-control:
Via standard DMX-controller
On Board:
Display for easy Set Up
Control:
DMX-512, Built-in Programs, Auto, Manual color,
Master/Slave, Sound
Beam Angle:
35°
Dimmer:
0-100%
Strobe:
0-20Hz
Housing:
Die Cast Aluminium Powder Coat Finish
Connections:
Dedicated IEC Power & Dataconnector
Cooling:
Convection (no fans) which eliminates the use of fans and
noise
Design:
Stylish
Lens Plate:
Tempered Glass
Lux (@ 2 meter):
RGB 2010
Included:
Schuko to IEC powercable
Max. ambient temperature t
a
: 40°C
Max. housing temperature t
B
: 80°C
Minimum distance:
Minimum distance from flammable surfaces:
0.5m
Minimum distance to lighted object:
1m
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
Email: service@highlite.nl

SHOWTEC compact par 7 MKII Specifications

General

Brand	SHOWTEC
Model	compact par 7 MKII
Category	Flood Light
Language	English
