SHOWTEC Phantom 300 Spot - Channels (ADVANCED)

18
DMX Protocol 22 Channels (ADVANCED)
Channel 1 - Horizontal movement (Pan)
Push the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 - Pan fine 16 bit
Channel 3 - Vertical movement (Tilt)
Push the slider, up in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 4 - Tilt fine 16 bit
Channel 5 –PAN/TILT Speed
0-255
From Max Speed (0) to Min. Speed (255)
Channel 6 –PAN/TILT Macro
0-15
No Function
16-45
Pan/Tilt Macro 1 (fast)
46-75
Pan/Tilt Macro 2 (fast)
76-105
Pan/Tilt Macro 3 (fast)
106-135
Pan/Tilt Macro 4 (fast)
136-165
Pan/Tilt Macro 5 (slow)
166-195
Pan/Tilt Macro 6 (slow)
196-225
Pan/Tilt Macro 7 (slow)
226-255
Pan/Tilt Macro 8 (slow)
Channel 7 – Shutter / Strobe (Dimmer must be open )
0-3
Shutter closed / Blackout
4-7
Shutter open
8-127
Strobe effect, from slow to fast (0-10 flashes/sec.)
128-191
Pulse-effect, in sequences from slow to fast
192-223
Shutter Effect
224-251
Random strobe effect, from slow to fast
252-255
Shutter open
Channel 8 – Shutter Macro
0-31
No Function
32-59
Blackout during Pan/Tilt movement
60-87
Blackout during Static Gobowheel movement
88-115
Blackout during Pan/Tilt or Static Gobowheel movement
116-143
Blackout during Colorwheel movement
144-171
Blackout during Pan/Tilt or Colorwheel movement
172-199
Blackout during Static Gobowheel or Colorwheel movement
200-227
Blackout during Prism movement
227-255
Blackout during Pan/Tilt, Static/Rot. Gobowheel, Colorwheel or Prism
Channel 9 – Dimmer intensity
0-255
From black to brightest
Channel 10 – Dimmer Fine
