Adjusting Output Levels
Access the analog output levels through the web application, by selecting an output level from the Analog Gain (dB) pull-down
menu. Match the output level from the Network Interface to the input sensitivity on the analog device:
Line level (0 dB)
Aux level (-20 dB)
Microphone level (-46 dB)
LED Signal and Clipping Indicators
Each analog output channel has a corresponding LED:
Green: Audio signal present
Red: Audio signal is clipping and should be attenuated.
Note: the meters in the web application are not affected by the Analog Gain (dB) setting.
Pre- and Post-Fader Metering
There are two modes for monitoring so that both the input and output signals can be monitored separately.
When set to pre-fader, the meter displays the signal level from the source on the Dante network. If signals are too low or clip
ping, adjust them at the source.
When set to post-fader, the meter is affected by the digital gain. It is not affected by the output analog gain setting.
Using a Third-Party Control System
This device receives logic commands over the network. Many parameters controlled through Designer can be controlled using
a third-party control system, using the appropriate command string.
Common applications:
Mute
LED color and behavior
Loading presets
Adjusting levels
A complete list of command strings is available at:
pubs.shure.com/command-strings/ANI4OUT.
Networking and Dante
Digital Audio Networking
Dante digital audio is carried over standard Ethernet and operates using standard Internet Protocols. Dante provides low la
tency, tight clock synchronization, and high QualityofService (QoS) to provide reliable audio transport to a variety of Dante de
vices. Dante audio can coexist safely on the same network as IT and control data, or can be configured to use a dedicated net
work.
