RECEIVER MOUNTING
Single Rack–Mounted Receiver (Figure 6)
If the receiver is to be located on a table or other horizontal surface, attach the four
adhesive bumpers to the bottom corners of the receiver. If the receiver is to be mounted
in an audio equipment rack, identify the rack-mount kits supplied with your system and
follow the appropriate assembly directions below.
1. Remove two screws from each side of the receiver.
2. Position the large mounting brackets over the holes on the sides of the receiver and
secure them to the receiver with the screws removed in Step 1.
3. If you are not going to front mount the antennas with a Shure WA503 Front Mount
Conversion Kit, insert the plastic plugs into the holes in the brackets.
4. Secure the assembly to a standard audio equipment rack with four screws.
SINGLE RACK–MOUNTED RECEIVER
FIGURE 6
Double Rack–Mounted Receivers (Figure 7)
1. Remove the two screws on the outer side of each receiver.
2. Position the small mounting brackets over the holes on the outer side of each receiv-
er, and secure them with the screws removed in Step 1.
3. Remove the screws on the inner side of each receiver.
4. Position two link bars over the holes and secure them with the screws removed in
Step 3. For the receiver on the left, the link bar should be positioned so that its
threaded hole is toward the front of the receiver. For the receiver on the right, the
link bar should be positioned so that its threaded hole is toward the rear of the
receiver.
5. Place the two receivers next to each other so that the threaded holes in the link bars
line up, one on top of the other.
6. Fasten the receivers together by inserting a small screw from the top into the threaded
hole at the front of the link bar. Then insert the other screw from the bottom into the
threaded hole at the rear of the link bar.
7. Secure the assembly to a standard audio equipment rack, using four screws.
