If SW6000 is in use, the Agenda screen displays the agenda for an active meeting. Selecting an item displays full details. The
agenda is created in SW6000.
Messages
This buttons are reserved for future use.
Speak List
View the Speak, Request, and Reply lists.
Note: Interpreter units are always active and do not impact the speaker list.
The Speak list settings can be modified through the DIS-CCU web interface.
Home
The Home screen contains the following interface elements:
① Basic InformationIdentifies the current screen.
② Incoming Channel Selector
Indicators
Displays the channel number, language, and interpretation quality (see below) of
selected relay channels
③ Outgoing Channel Selector
Indicators
Displays the channel number and language for outgoing audio channels
④ Loudspeaker Channel
Indicator
Shows the channel the integrated loudspeaker is set to
⑤ NotificationsIndicates incoming messages, hardware connections, etc.
