Shure PSM1000 User Guide

BAND RANGE Output Power (mW)
G10 470-542 10/50/100
G10E 470-542 10/50
G11 479-542 6/10
H8Z 518-582 10/50
J8 554-626 10/50/100
J8E 554-626 10/50
K10E 596-668 10/50
L8 626-698 10/50/100
L8E 626-698 10/50
L9E 670-742 10/50
L10 670-742 10/20
P8 710-790 10/50
Q21 710-787 10/50
Q22E 750-822 10/50
Q23 750-822 10/20
R26 794-806 6/10
R27 794-806 10/50
A24 779-788 797-806 6/10
X1 944-952 10/50/100
X2 925-932 10/50
Certifications
P10T, P9R
Meets requirements of the following standards: EN 300 422 Parts 1 and 2, EN 301
489 Parts 1 and 9, EN60065.
Meets essential requirements of the following European Directives:
• R&TTE Directive 99/5/EC
• WEEE Directive 2002/96/EC, as amended by 2008/34/EC
• RoHS Directive 2002/95/EC, as amended by 2008/35/EC
Note: Please follow your regional recycling scheme for batteries and electronic
waste
P10R
Approved under the Declaration of Conformity (DoC) provision of FCC Part 15.
Certified in Canada by IC to RSS-123.
P10T
Certified under FCC Part 74.
Certified by IC in Canada under RSS-123 and RSS-102.
The CE Declaration of Conformity can be obtained from Shure Incorporated or any
of its European representatives. For contact information please visit www.shure.
com
The CE Declaration of Conformity can be obtained from: www.shure.com/europe/
compliance
Authorized European representative:
Shure Europe GmbH
Headquarters Europe, Middle East & Africa
Department: EMEA Approval
Jakob-Dieffenbacher-Str. 12
75031 Eppingen, Germany
Phone: 49-7262-92 49 0
Fax: 49-7262-92 49 11 4
Email: EMEAsupport@shure.de
NOTE: This Radio equipment is intended for use in musical professional
entertainment and similar applications. This Radio apparatus may be capa-
ble of operating on some frequencies not authorized in your region. Please
contact your national authority to obtain information on authorized frequen-
cies and RF power levels for wireless microphone products.
ACCESSORIES AND PARTS
Furnished Accessories
P10R Antenna
470–542 MHz
UA700
540–626 MHz UA710
596–692 MHz
UA720
670–830 MHz
UA730
830–952 MHz
UA740
P10T Antenna
470–542 MHz
UA820G10
554-626 MHz UA820J8
596-668 MHz UA820K1
626-698 MHz UA820L8
670-742 MHz UA820LCH
710-790 MHz UA820P8
774-865 MHz UA820A
944-952 MHz UA820X
518-582 MHz UA820H8
Front Mount Antenna Cable 95A9023
Zipper Bag 95A2313
Hardware Kit (Rack mounting Screws) 90AR8100
Bumper Kit 90B8977
AA Adapter 90XN1371
Optional Accessories
8-to-1 antenna combiner for better RF
performance
PA821SWB
4-to-1 antenna combiner with power dis-
tribution to 4 transmitters (better RF per-
formance and eliminates need for external
power supply)
PA421SWB
Passive Directional Antenna PA805SWB
Helical Antenna HA-8089
Passive Omnidirectional Antenna UA860SWB
Coaxial Cable, BNC-BNC, RG58C/U type,
50 Ohm, 2 ft length (0.6 m)
UA802
Coaxial Cable, BNC-BNC, RG58C/U type,
50 Ohm, 6 ft length (2 m)
UA806
Coaxial Cable, BNC-BNC, RG8X/U type,
50 Ohm, 25 ft length (7.5 m)
UA825
Coaxial Cable, BNC-BNC, RG8X/U type,
50 Ohm, 50 ft length (15 m)
UA850
Coaxial Cable, BNC-BNC, RG213/U Type,
50 Ohm, 100 ft length (30 m)
UA8100
14

Shure PSM1000 Specifications

General

Frequency Range	470–952 MHz (country dependent)
Operating Range	100 m (328 ft) (Typical)
Audio Input	XLR
Network Interface	Ethernet
Receiver Audio Output	XLR, 1/4" (6.3 mm) balanced/unbalanced
Receiver Battery Type	AA
Power Supply	100 to 240 V AC, 50-60 Hz
Weight	Varies by model (refer to specific model documentation)
