G:
Group number. Each group contains channels selected to work well together in a single installation.
CH:
Channel number. Sets the receiver to a channel in the selected group.
888.888 MHz
Displaysthefrequencytowhichthereceiverisset.Highlightandusethe▼▲buttonstosettoaspecificfrequency.
SQUELCH
Adjusts the squelch setting.
RF PAD
Attenuates antenna signals in 3 dB increments.
Audio Settings
Access the following audio settings from the Audio menu.
Output Mode (MODE)
STEREO
Receive left and right inputs as a stereo signal
MIXMODE
®
Set your receiver to combine the left and right channel for simultaneous listening in both ears or pan to listen to only the
left or right channel
Four-Band Parametric Equalizer (EQ)
The parametric equalizer is divided into four frequency bands: LOW, LOW MID, HIGH MID, and HIGH. When the EQisen
abled, the following parameters are adjustable:
FREQUENCY
Select the center frequency of the band to boost/cut
Q
Adjusts the width and slope of the frequency band (measured in octaves)
GAIN
Adjustable in 2 dB increments from -6 dB (cut) to +6 dB (boost)
NOTE: HIGH and LOW are shelf filters, and therefore do not have adjustable Q widths. The HIGH shelf is fixed at 10 kHz; the LOW shelf is fixed at 100 Hz.
