Shure UR5 - UR5 Portable Receiver Components

6
UR5 Portable Receiver
① Power Switch
Turnstheportablereceiveronandoff.
② TA3M Jack.
Foraudioout.
③ 3.5 mm Headphone Jack
Formonitoringaudio.
④ Scan Button
Pressthescanbuttontofindthenextavailablechannel.Pressandholdfortwo
secondstofindthegroupwiththemostavailablechannels.
⑤ IR Window
FortransferringRFsettingsandnametoatransmitter,orcopyingtheMTxlistto
anotherreceiver.
⑥ Battery Compartment
Install2AAbatteriesoraShureSB900rechargeablebattery.Openbypressingthe
latchesonbothsidesandpullingoutward.
⑦ Menu Buttons
Useinconjunctionwiththe▼▲buttonstoaccesstheconfigurationmenus.
⑧ ▼▲ Buttons
Usetoscrollthroughmenus,changesettings,orselecttransmittersinMTxmode.
Canbeassignedtocontrolheadphoneorcameraoutputvolumes.
⑨ LCD Screen
Displayscurrentsettingsandmenus.
⑩ Tri-Color Battery LED
Illuminatesgreen,amber,orredtoindicatebatterypower.Whenred,change
batteriesimmediately.
⑪ Blue RF LED
Indicatestheportablereceiverisreceivingasignalfromthetransmitter.
⑫ Detachable Antennas (2)
SMAConnectors(2)
⑬ Power Through Contacts
ForpoweringthereceiverwheninsertedintotheShureAFP522DCcameramount.
Thereceiverautomaticallyswitchestointernalpowerwhenremovedfromthemount
orexternalpowerislost.
⑭ Removable AA Adapter
RemovetousewithaShureSB900rechargeablebattery.
Note:Toremoveadapter,opendoorandslideadapterout.Toreinstall,pressthe
adapterintoplace—thereisanaudibleclickwhenseated.
