ATTACHING 2000-1 RAILS WITH CARRIAGE TO STAND-ENDS
STEP 2
ITEMS REQUIRED
2000-1 Rails
Carriage
Stand-End Assembly
1. Position the carriage and rails so the four bolts fit into the bolt holes on the stand ends. (Pic 2.1)
2. Add washers and hand tighten lock nuts. (Pic 2.2)
3. Check for square alignment of the stand and rails. Nudge the bottom edge of the stand-ends to align. (Pic 2.3)
4. Tighten the eight lock nuts under the rails and on each stand-end. Once tightened add nut caps to all eight lock
nuts.
5. Add handles to the carriage. (Pic 2.4)
