Shuttle Mini-PC - Connectors of the Shuttle Mini-PC Complete System

Optical Drive (optional)1.
Card reader2.
IDE Status LED3.
Power Status LED4.
Bluetooth Status LED (optional)5.
WLAN Status LED (optional)6.
Reset Button7.
Power-On Button8.
External 3.5" Drive9.
(Audio) Microphone10.
(Audio) Headphones11.
USB Connectors12.
Firewire Connectors13.
eSATA Connectors14.
Touchscreen Display15.
Function Buttons for Display16.
VFD Display17.
Eject button for optical drive18.
Release button for drive slot 19.
Drive slot for 2.5" mobile racks20.
Speed-Link Button21.
Fingerprint Scanner (optional)22.
Wireless LAN Antenna (optional)23.
Optical SPDIF Connector (optional)24.
Coaxial SPDIF Connector (optional) 25.
Connector for mains plug26.
Connector for external power supply27.
Additional expansion card (optional)28.
Graphics card (optional)29.
Serial Interface30.
Parallel Interface (optional)31.
Ethernet32.
PS/2 Mouse connector33.
PS/2 Keyboard connector34.
(Audio) Line-IN L/R35.
VGA-output36.
DVI-output37.
TV-output (optional)38.
HDMI-output39.
Component-output40.
Connectors for infra-red receivers41.
Infra-red receiver (optional)42.
External power supply for eSATA 43.
hard disks
Clear CMOS button44.
(Audio) Center/Bass45.
(Audio) Surround back L/R46.
(Audio) Line-out L/R47.
(Audio) Surround front L/R48.
