SIA IHDR80BL - Page 12

12
600
800
520
404
800~1000
500
293
239
321
321
MIN.105
154
110
104
240
285
370
700
35
Fig.1
Fig.2
Accessory List
Installation Manual
Downdraft
Induction Hob
Overall installation size
1. ST4*10 screws
2. Aluminium tape
3. Rectangular aluminium
duct channels
4. Inlet grille
5. Grease filter
6. Extraction box
7. Water retainer
8. Motor
9. Adaptor
10. Induction hob
11. Fixing brackets
12. ST4*13 Screws
（for junction box）
13. ST3.5*8 Screws
（for fixing brackets）
1
11x
11
12
13
4x
4x
4x
4x
9
10
2
3
4
5
6
7
8
