6. List of measurements. In this mode up to the three measurements for
the current date and well number can be shown in the title. In the each
line of measurements the time of measurement, quantity of reflections
and the measured fluid level are indicated. Pressing "INPUT/OUTPUT"
button — jump to the next measurement. Pressing BACK and
"INPUT/OUTPUT" button simultaneously— jump to the previous
measurement. Symbol > indicates the cursor. Pressing "MODE" button
activates the graph of measurement, marked with cursor.
7. In the example the measurements are shown for date the 26th of
September and number of well 678943. The measurement, marked with
cursor, has been carried out at 16: 53, the measured fluid level was
1030 meters and 2 reflections have been determined. The previous
measurement had been carried out at 16: 51, the fluid level was 1027
meters and 2 reflections had been determined.
8. Visualisation of the echogram graph. The operation in this mode is
described in detail in Supplement 7.
5.3.5. Turning the tool on and turning it off
ATTENTION! Before turning on the tool for the first time after
it has been stored for a long time or transported, it is necessary to fully
charge the battery cell (see Supplement 4). Only after having charged
the battery the tool may be turned on. Otherwise, the tool cannot be
switched on or it can switch off immediately after having been turned
on. But this does not mean that the tool has any default.
