SIATA AQUA IONIC - Meaning of LEDs and Keys

Aqua Ionic - 5 di 24
3 – MEANING OF LEDs AND KEYS
LED functionality (Tab. 1)
SET POINT
(yellow case)
It is on during the set point value setting.
SET POINT
(blue case)
It is on when the conductivity value surpasses the set point value.
ALARM (blue case)
SET POINT DELAY
(yellow case)
It goes on during programming when setting the set point intervention time.
During operation, it illuminates to indicate an alarm condition.
EXT. ALARM
It is on when the inhibition signal is present.
AUTO SET POINT
It is on when the regeneration must start because water is not good.
AUTO VOLUME
It is on when the regeneration must start because of exhausted volume.
MANUAL
It is on when the regeneration must not start automatically.
INT. ALARM
It is on when regeneration is not successful.
Fig. 1
