8 Accessories
8.1 Brackets
SICK offers prefabricated brackets which are optimally suited for mounting the device
in a wide range of applications. Also see on Internet at:
■
www.sick.com/CLV62x
■
www.sick.com/CLV63x
■
www.sick.com/CLV64x
Figure 22: Example: Optional bracket for CLV62x, CLV63x and CLV64x fixed mount bar code
scanners with front viewing window in IP69K protective housing, here round pole bracket with
mounting bracket, part no. 2068599
Figure 23: Example: Optional bracket for CLV62x, CLV63x and CLV64x fixed mount bar code
scanners with oscillating mirror and side viewing window, in IP69K protective housing, here
mounting plate, part no. 2068602
8.2 Cables
NOTICE
The following requirements must be met in order to achieve the IP69K enclosure rating:
•
Use only the connection cables specified by SICK.
•
Seal the two cable outlets at the protective double bushing with the corresponding
O-rings.
•
The recessed flat seal on the side facing the protective housing is undamaged.
The O-rings are included in the device scope of delivery and are matched to the outer
diameters of the plug connectors.
The following connection cables are available as accessories for the devices.
8 ACCESSORIES
40
T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing 8021479/19ZB/2021-10-29 | SICK
Subject to change without notice
