FLOWSIC600 DRU
FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V1-6/2018-05 · © SICK Engineering GmbH 13
2.4
Technical data
Table 2 Technical data FLOWSIC600 DRU
Meter characteristics and measuring parameters
Measured values Operational volume flow, operational volume, gas velocity, sound velocity
Measurement principle Ultrasonic transit time difference measurement
Number of measuring
paths
2
Measuring medium Natural gas
Measuring ranges Operational:
3 inch: Q
min
1
Q
t
Q
max
2
Flow velocity [ft/s] 3 10 150
Flow velocity [m/s] 0.9 3.0 45.0
Volume flow rate [ft³/h] 495 1650 24770
Volume flow rate [m³/h] 14 47 700
4 inch: Q
min
1
Q
t
Q
max
2
Flow velocity [ft/s] 3 10 122
Flow velocity [m/s] 0.9 3 37
Volume flow rate [ft³/h] 860 2875 35000
Volume flow rate [m³/h] 25 81 1000
6 inch Q
min
1
Q
t
Q
max
2
Flow velocity [ft/s] 3 10 115
Flow velocity [m/s] 0.9 3 35
Volume flow rate [ft³/h] 1950 6500 75000
Volume flow rate [m³/h] 55 185 2125
1
Below 3 ft/s increased uncertainty.
2
Qmax can be limited by the working pressure and attenuation of the gas medium.
Repeatability ± 0.2 % of reading
(within Q
t
to Q
max
under consideration of installation requirements)
Uncertainty ± 1 % from Q
t
to Q
max
(± 2 % from Q
min
to Q
t
)
Gas temperature -40 ... 185 °F
Operating pressure 0 … 1480 psig at 100 °F
0 … 1380 psig at 185 °F
Nominal pipe size 3 inch Schedule 80 / 4 inch Schedule 80 / 6 inch Schedule 80
Flange connection 3 inch ANSI B16.5, Cl.600 RF / 4 inch ANSI B16.5, Cl.600 RF / 6 inch ANSI B16.5,
Cl. 600 RF
Ambient conditions
Ambient temperature -40 ... 140 °F
Storage temperature -40 ... 158 °F
Ambient humidity ≤ 95 % Relative humidity
Approvals
Ex approvals NEC/CEC Class I, Division 1, Group D T4
Class I, Division 2, Group D T4
Ultrasonic transducers intrinsically safe
Enclosure rating IP66/IP67
Outputs and interfaces
Digital outputs 2 DO and 1 FO:
30 V, 10 mA
Passive, galvanically isolated, open collector, fmax = 6 kHz (scalable)
Interfaces RS-485 (2x, for configuration data output and diagnosis)
