16 FLOWSIC600 · Addendum to Operating Instructions · 8017812/ZYM6/V1-6/2018-05 · © SICK Engineering GmbH
FLOWSIC600 DRU
2.5.2 FLOWSIC600 DRU 6"
A B C D E
All dimensions in mm (in)
6" 1950
(76.77)
146.4
(5.76)
285
(11.22)
462
(18.20)
355.6
(14.00)
