Output Description
Muting lamp Data type: Boolean
T
he Muting lamp output can be used to indicate when a muting cycle is
active.
•
The Muting lamp output = 0 if the Muting status output = 0
•
The Muting lamp output = 1 if the Muting status output = 1 or the
Override status output = 1
•
The Muting lamp output pulsates at 2 Hz if the Override required output
= 1
Muting status Data type: Boolean
T
he output indicates the status of the muting function.
•
The Muting status output = 0 if the muting cycle is inactive (no error)
or a muting error has been detected
•
The Muting status output = 1 if the muting cycle is active (no error) or
override is active (no error)
Override required Data type: Boolean
Muting error Data type: Boolean
"Out
put Muting error", page 103
Override status Data type: Boolean
Status Data type: Boolean
•
0 = Er
ror
•
1 = No error
The value at the output is the inverted value of the Muting error output.
Table 114: Parameter
Parameter Description
Direction detection
•
Dis
abled
•
Forward (A1 / A2 first)
•
Backward (B1 / B2 first)
"Parameter Direction detection", page 104
Condition of the other sen‐
sor pair f
or muting start
•
Bo
th sensors clear
•
At least one sensor clear
"Parameter Condition of the other sensor pair for muting start",
page 105
Condition for end of muting
•
W
ith muting sensor pair
•
With electro-sensitive protective device (ESPE)
"Parameter Condition for end of muting", page 105
Total muting time 0 = infinite, 5 s … 3,600 s, adjustable in 1 s increments
"P
arameter Total muting time", page 104
Concurrency monitoring
t
ime
0 = infinite, 10 … 3,000 ms, adjustable in 10 ms increments. If
the value is not 0, it must be greater than the logic execution time.
"Parameter Concurrency monitoring time", page 104
