TECHNICAL DATA 8
8.1.3 Position of connections
Purging of enclosure (option), gas inlet
Purging of enclosure (option), gas outlet
LAN
Power supply. The cable inlets are suitable for cables with outer diameter 7 ...12 mm.
I/O. The cable inlets are suitable for cables with outer diameter 7 ...12 mm.
Second gas path, gas inlet
Second gas path, gas outlet
Gas inlet
Gas outlet
Bonding load connection
