SICK i110RP User Manual

6 Technical data
6.1 General system data
i110-RP223
i110-R
P313
i110-RP224
Housing material Light-alloy diecast, varnished
Eye nut Stainless steel
Enclosure rating (IEC 60529) IP66
Mechanical life 1 × 10
6
s
witching operations
B
10D
(EN ISO 13849-1) 2 × 10
6
with low load
Type Type 1 (EN ISO 14119)
Actuator coding level Uncoded (EN ISO 14119)
T
M
(mis
sion time) 20 years
Operating temperature –25°C … +80°C
Mounting orientation any
Type of connection Cable entry 1 × M20 Plug connection 1 × M12
(4-pin)
Actuation force (EN 60947-5-5) < 125N (300mm deflection)
Tensile force for operating position (nor‐
mal v
alue)
103 N
Tensile force for inhibit (normal value) 188 N
Rope length max. 30m
Actuation frequency max. 1 cycle/second
Contact elements positively guided NC
c
ontacts/NO contacts
i110-RP223: 2/2
i110-RP313: 3/1
2/0
Rated impulse withstand voltage U
im
p
contacts referred to housing
2500V 1500V
Rated insulation voltage U
i
250V 30V
Usage category (EN 60947-5-1) AC-15: 240 V/3 A
DC
-13: 24 V/2 A
DC-13: 24 V/2 A
Switching voltage min. 5VDC
Switching current min. at 5 V DC 5mA
Connection cross-section 1 × 1,5mm² –
Short-circuit protection T6 2A
Torque requirements for screws
Mounting screws housing 5,0Nm
Cover screws 2,0Nm
Jam screws contacts 1,0Nm
TECHNICAL DATA 6
8027296/1KR8/2023-07-31 | SICK O P E R A T I N G I N S T R U C T I O N S | i110RP
13
Subject to change without notice
