1
Device
2
Connection cable 1:1 (female connector, M12, 17-pin, A-coded / male connector, M12, 17-pin, A-coded)
3
Connection module: female connector, M12, 17-pin, A-coded
4
Device: male connector, M12, 17-pin, A-coded
NOTE
User of the RS-422 data interface:
Control the RS-422 data interface in the device with the API functions. In order to
activate the RS-422 data interface, use an installed SensorApp which contains
this function.
13.3.6 Wiring the CAN interface in the CDB650-204
ANNEX 13
8024439//2019-06 | SICK O P E R A T I N G I N S T R U C T I O N S | InspectorP621
59
Subject to change without notice
