1. Press the SET pushbutton.
2. Use the plus or minus pushbutton to select Pro.
3. Press the SET pushbutton.
4. Use the plus or minus pushbutton to select Job.
5. Press the SET pushbutton.
6. Use the plus or minus pushbutton to choose between Sto (store) and LoA (load).
Store
Load
7. Press the SET pushbutton.
8. Use the plus or minus pushbutton to select one of the 5 memory locations (in this
case, Job3).
9. Press the SET pushbutton.
7.8.8 Adjusting the color fixation
NOTE
During 1P teach (color mode), this function is deactivated.
You can use the color fixation to restrict the light source to one particular sender color
(red, green, or blue). In the factory setting, the sender color is set to automated.
1. Press the SET pushbutton.
2. Use the plus or minus pushbutton to select Pro.
3. Press the SET pushbutton.
4. Use the plus or minus pushbutton to select Col.
5. Press the SET pushbutton.
6. Use the plus or minus pushbutton to select Sender color.
7 OPERATION
38
O P E R A T I N G I N S T R U C T I O N S | KTS/KTX Prime 8020708.ZMT3/ | SICK
Subject to change without notice
